Alcovisor Phoebus Access Control Breathalyzer Standard

Alcovisor Phoebus Access Control Breathalyzer Standard

Ensure a safe and compliant workplace with the Alcovisor Phoebus Access Control Breathalyzer Standard, the definitive solution for South African businesses. Designed to meet the rigorous demands of industries from mining to logistics, this device is your first line of defense in preventing alcohol-related incidents and upholding your duties under the Occupational Health and Safety Act.

The Alcovisor Phoebus Access Control Breathalyzer Standard is more than just a testing unit; it’s a smart, adaptable safety solution. Its modern Android operating system and Wi-Fi capability allow for effortless remote management and software updates. Use the clear on-screen display to reinforce your safety culture by playing company policy videos or essential safety awareness messages before granting access.

Whether you need a versatile stand-alone self-tester for your employees or a fully integrated solution for your existing security system, the Alcovisor Phoebus Access Control Breathalyzer Standard delivers. It’s the ideal choice for ensuring every individual entering a high-risk area—be it a factory floor, construction site, or transport depot—is fit for duty.

Key integration and communication features include:

• Direct Access Control: An output relay contact automatically triggers gates, turnstiles, or door locks upon a “Pass” result, ensuring seamless entry for sober individuals.
• Smart System Communication: Utilizes RS232 serial communication to instantly transmit “Fail” signals to your security software, logging the event and preventing access.

Optional Upgrade: For maximum compatibility, an external Wiegand converter is available. If your current access control system doesn’t support RS232, this module ensures the Phoebus can communicate “Ready,” “Fail,” or “Pass” signals, making it compatible with virtually any security infrastructure in South Africa.

SPECIFICATIONS

• Sensor Technology: Law-Enforcement Grade Electrochemical Fuel Cell for precision and reliability.
• Operating System: Android OS for a user-friendly and stable experience.
• Memory Capacity: 8GB Internal Storage.
• Test Record Storage: On-board memory for up to 20,000 test results.
• Operating Temperature: Built for tough South African conditions (-10°C to 50°C).
• Storage Temperature: -20°C to 50°C.
• Humidity Range: 20% to 95%.
• Dimensions: 20cm x 24cm x 11cm.
• Weight: 1588g.
• Power Supply: AC 100-240V 50-60Hz | DC12V 3A.
• Fast Response Time: Results in under 5 seconds.
• Sampling Method: Automated deep-lung air sampling for accurate measurement.
• Units of Measure: BrAC: mg/L | BAC: grm%, mg/mL, mg/100ml.
• Detection Range: 0.00% BAC to 0.40% BAC.
• Certified Accuracy: 0 – 0.10% BrAC +/-5% | 0.10 – 0.15% BrAC +/-8% | >0.15% +/-10%.
• Easy Maintenance: The alcohol testing module is fully replaceable for simple on-site calibration and service.
• Sample Time: Requires a 4-second continuous breath sample.
• Rapid Recovery Time: Ready for the next test just 30 seconds after a positive result.
• Full Access Control Communication: Output Relay (N/O, N/C) | RS232 Serial Port | Optional Wiegand Converter with I/O Expander.
• Connection Port: USB for data transfer.
• Network Connectivity: Wi-Fi, Ethernet, and optional 4G.
• NFC Support: Integrated NFC reader for card-based identification.

Protect your workforce, your assets, and your business reputation. Contact us today for a quote or to schedule a demonstration of the Alcovisor Phoebus Access Control Breathalyzer Standard.
